SLTN RP Non-Metallic Anti-Rodent Fiber Optic Cable
Specialized non-metallic anti-rodent cable with FRP core and glass yarn rodent barrier. 2–144 cores for underground and duct deployment in rodent-prone environments with dry cable core design.
| Cable Type | SLTN RP (Non-Metallic, Anti-Rodent) |
| Fiber Count | 2–144 cores |
| Attenuation @1310nm | ≤0.36dB/km |
| Attenuation @1550nm | ≤0.22dB/km |
| Rated Tensile Strength | 4000–4500N (short-term), 600–1500N (long-term) |
| Operating Temperature | -40°C to +70°C |
Specifications
| CABLE TYPE | SLTN RP (Non-Metallic, Anti-Rodent) |
| FIBER COUNT | 2–144 cores |
| FIBER TYPE | G.652D single-mode |
| INSTALLATION | Duct, underground |
| ATTENUATION @1310NM | ≤0.36dB/km |
| ATTENUATION @1550NM | ≤0.22dB/km |
| CABLE DIAMETER | 10.5–16.3mm |
| WEIGHT | 90–220 kg/km |
| RATED TENSILE STRENGTH | 4000–4500N (short-term), 600–1500N (long-term) |
| CRUSH RESISTANCE | 3000N/100mm (short-term), 1000N/100mm (long-term) |
| OPERATING TEMPERATURE | -40°C to +70°C |
| STRENGTH MEMBER | FRP central strength member |
| CONSTRUCTION | Non-metallic core, glass yarn anti-rodent |
| JACKET MATERIAL | PE outer sheath with swell water-blocking tape |
| STANDARDS | IEC 60794-1 · YD/T 901 |
