GYHTY Non-Metallic Reinforced Stranded Fiber Optic Cable
Fully dielectric stranded loose tube cable with FRP core and aramid yarn reinforcement. 2–36 cores for duct and aerial deployment in lightning areas and near power lines.
| Cable Type | GYHTY (Stranded Loose Tube, Non-Metallic Reinforced) |
| Fiber Count | 2–36 cores |
| Attenuation @1310nm | ≤0.36dB/km |
| Attenuation @1550nm | ≤0.22dB/km |
| Rated Tensile Strength | 1500N (short-term), 600N (long-term) |
| Operating Temperature | -40°C to +70°C |
Specifications
| CABLE TYPE | GYHTY (Stranded Loose Tube, Non-Metallic Reinforced) |
| FIBER COUNT | 2–36 cores |
| FIBER TYPE | G.652D single-mode |
| INSTALLATION | Duct, aerial |
| ATTENUATION @1310NM | ≤0.36dB/km |
| ATTENUATION @1550NM | ≤0.22dB/km |
| CABLE DIAMETER | 10.7mm |
| WEIGHT | 90 kg/km |
| RATED TENSILE STRENGTH | 1500N (short-term), 600N (long-term) |
| CRUSH RESISTANCE | 1000N/100mm (short-term), 300N/100mm (long-term) |
| OPERATING TEMPERATURE | -40°C to +70°C |
| STRENGTH MEMBER | FRP central strength member |
| CONSTRUCTION | Fully dielectric, non-metallic |
| JACKET MATERIAL | PE inner + PE outer sheath |
| STANDARDS | IEC 60794-1 · YD/T 901 |
