GYFXY Central Loose Tube Non-Metallic Non-Armored Fiber Optic Cable
All-dielectric non-metallic outdoor fiber cable with FRP reinforcement and central loose tube design. 2–24 cores for duct and indoor/outdoor applications. Lightning-safe.
| Cable Type | GYFXY (Central Loose Tube, Non-Metallic) |
| Fiber Count | 2–24 cores |
| Attenuation @1310nm | ≤0.36dB/km |
| Attenuation @1550nm | ≤0.22dB/km |
| Rated Tensile Strength | 1500N (short-term), 800N (long-term) |
Specifications
| CABLE TYPE | GYFXY (Central Loose Tube, Non-Metallic) |
| FIBER COUNT | 2–24 cores |
| FIBER TYPE | G.652D single-mode |
| INSTALLATION | Duct, indoor/outdoor |
| ATTENUATION @1310NM | ≤0.36dB/km |
| ATTENUATION @1550NM | ≤0.22dB/km |
| CABLE DIAMETER | 8.0mm |
| WEIGHT | 58 kg/km |
| RATED TENSILE STRENGTH | 1500N (short-term), 800N (long-term) |
| CRUSH RESISTANCE | 1000N/100mm (short-term), 300N/100mm (long-term) |
| OPERATING TEMPERATURE | -40°C to +70°C |
| STRENGTH MEMBER | Two parallel FRP rods |
| CONSTRUCTION | All-dielectric, non-metallic |
| JACKET MATERIAL | PE outer sheath |
| STANDARDS | IEC 60794-1 · YD/T 1158 |
