Indoor Multi-Core Micro Fiber Cable — MFC
Ultra-compact micro fiber cable (MFC) using bare color-coded fibers for maximum density. Up to 144 cores in a remarkably small diameter. Aramid yarn reinforcement with PVC or LSZH outer jacket. Ideal for high-density data center cabling.
| Cable Type | MFC (Multi-Core Micro Fiber Cable) |
| Fiber Count | 12-144 cores |
| Fiber Type | G.652D SM 9/125 / OM3-OM4 MM 50/125 |
| Fiber Format | 250um bare color-coded fiber |
| Cable Diameter | 3.5mm (12-core) to 15.5mm (144-core) |
| Jacket Material | PVC or LSZH |
Specifications
| CABLE TYPE | MFC (Multi-Core Micro Fiber Cable) |
| FIBER COUNT | 12–144 cores |
| FIBER TYPE | G.652D SM 9/125 / OM3-OM4 MM 50/125 |
| FIBER FORMAT | 250um bare color-coded fiber |
| CABLE DIAMETER | 3.5mm (12-core) to 15.5mm (144-core) |
| JACKET MATERIAL | PVC or LSZH |
| STRENGTH MEMBER | Aramid yarn (Kevlar) |
| WEIGHT | 4.8–210 kg/km |
| TENSILE STRENGTH | 30–500N (short-term) |
| CRUSH RESISTANCE | 100–800N/100mm |
| BEND RADIUS | 100mm (static) / 200mm (dynamic) |
| OPERATING TEMPERATURE | -20C to +60C |
| STANDARDS | YD/T 1258.2 · ICEA-596 · GR-409 · IEC 60794-2 |
