Optical Fiber Flex Circuit
The optical fiber flex circuit is created from custom design files and parameters to route the fiber network in a compact and efficient manner. The use of rugged materials, provide reliable protection to the optical fiber, satisfying the rugged demands and rugged Industrial applications. Supported fiber types include single-mode、multi-mode or specialty fiber, such as Rad-Hard or Bend-Insensitive. Flex circuit designs may be as simple as a few fibers or as complex as hundreds of fiber nets.
● Custom routed flexible fiber circuit, improves fiber management.
● Simplifies system architecture, save space and improve airflow around temperature sensitive components.
lControlled bend radius，minimizes bend loss.
lFlame resistant substrate (VO rated), Durable and Reliable.
lReduced installation times and errors, cost savings.
lSupports all industry standard termination.
Optical Fiber Nominal OD | 250 μm |
Minimum Fiber to Fiber Spacing | 250 μm |
Circuit Thickness | 0.6 mm |
Maximum Circuit Dimensions | 500x500 mm |
Matched Length Tolerance | ±4 mm |
Maximum Insertion Loss | ＜0.1dB (before connectorized) |
Operation temperature | -40 ~ +85℃ |
Storage Temperature | -55 ~ +125℃ |
lOptical backplane interconnection
lHigh-density fiber management
lComplex fiber circuit routes in minimal space
lOptical Cross-Connects
lIntra-rack installation
