SMPTE Push-Pull Circular Connector
The Push-Pull Circular Connector series has a proven track record in various studio, stadium and outside broadcast installations, it is highly reliable, and is easy to maintain. Manufactured in stainless steel and excellent push-pull latching system, and is suitable for up to 20,000 mating cycles and above. employing high quality ceramic technology to achieve superb optical performance, with consistent physical contact of all the polished end faces.
Push-Pull self-latching system for quick and easy mating.
Easily cleaned fiber optic contacts and removable alignment sleeves.
Available with ruggedized stainless steel shells.
Available for connectorization from SMPTE to any fiber optic connector.
Standard ceramic pin and housing connection dimensions, fully compatible with existing equipment.
Three-key positioning design ensures the correctness of the primary connection of the multi-core fiber and can be plugged blind.
Consistent and reliable performance from precision engineering.
Lect standard connector on the other end，Various connector option: LC、SC、FC、ST etc.
Fiber Type | SM（9/125um） | MM（50/125um、62.5/125um） | |
Polish | UPC | APC | UPC |
Insertion Loss | Socket / Plug ≤1.0dB (Typical≤0.7dB) LC/SC ≤0.5 dB (Typical≤0.3dB)
| ||
Return Loss | UPC≥50dB，APC≥60dB | UPC≥20dB | |
mechanical character | Socket / Plug：≤1000N (Main Cable） | ||
LC/SC：≤ 100N（Branch Cable） | |||
Tensile Strength | Short term: 600N / Long term：200N | ||
Protection level | IP65 | ||
Fiber count(optional) | 1 ~ 4 | ||
Cable Diameter(optional) | 4.0、7.5mm(or Customize) | ||
Jacket Material(optional) | LSZH、TPU | ||
Anti-push Unit | KEVLAR | ||
Operating Temperature | -40 ~ +85℃ | ||
Broadcast
TV HDTV Cameras
Mobile/Van based TV Studios
Outdoor Events
Digital Camera Transmission
Re-deployable communications
Deployable broadcast networks and video transmission systems
